Saf-T-Cart 871-16FW-LE Firewall Cylinder Cart

The Saf-T-Cart 871-16FW-LE carries one large oxygen cylinder and one large acetylene cylinder with a steel firewall between them, so the oxygen and fuel gas stay separated while both ride on one cart. It rolls on 16" pneumatic tires for rough ground, and a lifting eye lets you hoist the cart for loading.

Which cylinders fit: one oxygen cylinder up to 9-1/2 in across and one acetylene cylinder up to 12-1/2 in across. It fits the common 300 cu ft acetylene cylinder, about 12 in across. The 16 in the model number is the wheel size, not a cylinder size. The two clamps are sized for full-size cylinders, so a much smaller cylinder will sit loose in them; if your acetylene cylinder is well under 12 in, ask us before ordering. How to check your cylinders.

Specification	Value
Oxygen cylinder, max diameter	9-1/2"
Acetylene cylinder, max diameter	12-1/2"
Wheels	Two 16" x 4" pneumatic tires with no-flat sealant
Height	65-1/2"
Width	34"
Cylinder hold-down	Two permaclamps
Lifting eye	Rated 1,000 lb
Firewall	Steel, at least 60" tall, 30-minute burn rating (manufacturer-stated)

The firewall helps satisfy OSHA 1910.253(b)(4)(iii) separation requirements for oxygen and fuel-gas cylinders in storage.

Manufactured in the USA by Saf-T-Cart in Clarksdale, Mississippi.
